How does an Impella device work?

The Impella pulls blood from the ventricle and pushes it out into the aorta, delivering oxygen-rich blood to the rest of your body. This allows your heart to rest while the doctor performs the PCI. Once the PCI procedure is complete, the Impella is turned off and guided out.

What does the placement screen show when the Impella 5.5 with SmartAssist device is correctly positioned across the aortic valve?

The Automated Impella Controller\u2122 (AIC) displays a red \u201cImpella Position in Ventricle\u201d alarm when it detects that the optical sensor on the Impella CP with SmartAssist or Impella 5.5 with SmartAssist is below the aortic valve, indicating that the Impella is too far into the left ventricle and both the inlet and outlet ...

When the Impella RP device is properly placed?

When Impella is correctly positioned, the inlet area of the device is about 3.5 centimeters below the aortic valve and the outlet area is in the aorta.

Can you do CPR on a patient with an Impella?

Cardiopulmonary support (CPR) should be initiated immediately per hospital protocol if indicated for any patient supported with the Impella® RP Catheter. When initiating CPR, reduce the Impella® RP Catheter flow rate.

How long can you stay on Impella?

It is designed to provide haemodynamic support for up to 30 days. Like the Impella 5.0, the Impella 5.5 device is an axial flow transaortic cardiac support device mounted on a 9 Fr steering catheter with a 21 Fr pump cannula.

Related forms

be ready to get more

Complete this form in 5 minutes or less

Get form

What does the LV mean on the Impella?

Impella Ventricular Support System is a small Left Ventricular Assist Device (LVAD). It is designed to help pump blood in patients who require short term support. The device is a tiny pump inside of a catheter with an electric motor that can deliver about 2.5 liters of blood per minute to the body.

What do the numbers mean on an Impella?

Impella Flow displays the additional amount of flow the patient is receiving. The large number displays the average amount of flow at the current P-level. Because the native heart is also providing flow, the fraction to the left of this number displays the max flow over the min flow during the cardiac cycle.

How does Impella measure cardiac output?

LVEDP is calculated using the pressure assessed in the aorta from the optical sensor and the pressure derived from the motor. The Impella CP with SmartAssist is designed to run at a constant motor speed in response to the real-time changes in pressures in the aorta and left ventricle.

What is Impella LD?

The Impella LD pump is a minimal invasive catheter- based cardiac assist device. It is designed to increase the cardiac output. The pump is designed to directly unload the left ventricle, reduce myocardial workload, reduce oxygen consumption and simultaneously increase cardiac output, coronary and end- organ perfusion.

What causes low purge pressure alarm Impella?

Suction, low pulsatility, and placement signal blocked are 3 of the more common reasons for Impella® heart pump alarms.
