The document provides specifications for the MIFAB Series F1100-EF round funnel floor drain designed for non-membrane floor areas. It details its construction from lacquered cast iron, features such as vandal-resistant screws, and functionality in environments like restaurants and hospitals where it manages indirect waste. The funnel design prevents splashing and directs waste into the drain, with various optional variations available for customization.
