There are several different types of ultrasonic testing, including: Automated Ultrasonic Backscatter Technique. Phased Array Ultrasonic Testing. Long Range Ultrasonic Testing. Internal Rotating Inspection Systems. Time of Flight Diffraction. Dry-Coupled Ultrasonic Testing. Rapid Ultrasonic Gridding (RUG)
A-scan displays the amplitude of received ultrasound signals as a function of time. B-scan produces a two-dimensional cross-sectional image by moving the transducer along an object. C-scan creates a planar two-dimensional image of internal structures without dismantling parts.
Ultrasonic testing relies on directing soundwaves with transducersdevices made of piezoelectric materials that convert electrical impulses to sound waves. With an ultrasonic instrument to initiate electrical impulses, the UT technician uses transducers to direct sound waves through the material in one of two modes.
Non-Destructive Testing (NDT) is used to collect information about a material in ways that do not alter it (i.e., without destroying it). Destructive Testing (DT) is used to collect information about a material in ways that do alter it (i.e., destroy it).
The Ultrasonic Testing (UT) characterizes the physical condition of an object using high frequency sound waves and can identify surface, subsurface and in volume defects, depending on its variant.
